New Process Water Treatment Equipment with Micro Sand Loading for
Enhanced Flocculation and Multi Effect Clarification
Product Description The micro sand loading multi effect clarification integrated
equipment is a new process equipment that uses micron level
selected quartz sand as a carrier on the basis of the existing
high-efficiency sedimentation tank to enhance the water treatment
effect.The equipment combines key technologies such as dosing
coagulation,micro sand enhanced flocculation,efficient
sedimentation,mud sand separation,and micro sand circulation.By
loading the microsand medium,the flocculation effect was
strengthened and the sedimentation rate was improved.The integrated
equipment for micro sand loading and multi effect clarification
ishighly integrated,with a surface load of 40-65m3/m2.h in the
sedimentation section and a total residence time of less than 20
minutes.The water treatment effect of the equipment:SS and TP
removal rates exceed 90%,COD removal rates reach up to 40%,with TP
effluent stable below 0.1mg/Land effluent turbidity stable below
5mg/L.Mainly used in areas such as overflow pollution
control,municipal sewage plant tail water standard improvement,and
pre-treatment of water plants.
Modelspecifications andrelated technical parameters
| Model | Capacity m³/h | Dissohedair quantity | Power Kw | Dimension(m) | Nozzle list |
| Reflowpump | Exhaust | Scavenger | Mixer | length | width | height | Iniet(A) | Outlet(B) | Sludge outlet(C) | Empty mouth(D) |
| WPG-1 | ~1 | ~0.7 | 0.55 | 0.55 | 0.2 | 0.4 | 1.7 | 0.55 | 1.1 | 32 | 32 | 40 | 32 |
| WPG-2 | ~2 | ~1 | 0.55 | 0.55 | 0.2 | 0.4 | 2.8 | 0.65 | 4.5 | 40 | 40 | 50 | 40 |
| WPG-3 | ~3 | ~2 | 0.75 | 0.55 | 0.2 | 0.4 | 3.5 | 0.8 | 1.6 | 80 | 80 | 80 | 50 |
| WPG-5 | ~5 | ~3 | 1.1 | 0.55 | 0.2 | 0.75 | 4 | 1 | 1.7 | 80 | 80 | 80 | 50 |
| WPG-10 | ~10 | ~4 | 1.5 | 0.75 | 0.2 | 0.75 | 5 | 1.2 | 2 | 100 | 100 | 100 | 80 |
| WPG-15 | ~15 | ~5 | 2.2 | 0.75 | 0.2 | 0.75 | 5.5 | 1.5 | 2 | 125 | 125 | 100 | 80 |
| WPG-20 | ~20 | ~7 | 3 | 0.75 | 0.2 | 0.75 | 5.8 | 1.8 | 2 | 150 | 150 | 100 | 80 |
| WPG-30 | ~30 | ~8 | 3 | 0.75 | 0.2 | 0.75 | 6 | 2 | 2.1 | 150 | 150 | 100 | 80 |
| WPG-40 | ~40 | ~9 | 4 | 0.75 | 0.2 | 0.75 | 7 | 2.2 | 2.1 | 200 | 200 | 100 | 80 |
| WPG-50 | ~50 | ~10 | 5.5 | 0.75 | 0.2 | 0.75 | 7.2 | 2.5 | 3 | 200 | 200 | 100 | 80 |
| WPG-60 | ~60 | ~10 | 5.5 | 0.75 | 0.2 | 0.75 | 7.4 | 2.5 | 3 | 200 | 200 | 100 | 80 |
| WPG-70 | ~70 | ~12 | 5.5 | 0.75 | 0.2 | 1.1 | 7.6 | 2.5 | 3 | 200 | 200 | 100 | 80 |
| WPG-80 | ~80 | ~12 | 5.5 | 0.75 | 0.2 | 1.1 | 7.8 | 2.5 | 3 | 200 | 200 | 100 | 80 |
| WPG-100 | ~100 | ~15 | 5.5 | 0.75 | 0.2 | 1.1 | 8 | 2.5 | 3 | 200 | 250 | 100 | 100 |
| WPG-120 | ~120 | ~15 | 5.5 | 0.75 | 0.4 | 2.2 | 8.5 | 2.5 | 3 | 250 | 250 | 200 | 100 |
| WPG-150 | ~150 | ~30 | 7.5 | 1.5 | 0.4 | 2.2 | 9 | 3.1 | 3 | 250 | 250 | 200 | 100 |
| WPG-200 | ~200 | ~30 | 7.5 | 1.5 | 0.4 | 2.2 | 10 | 3.1 | 3 | 250 | 350 | 250 | 100 |
| WPG-300 | ~300 | ~42 | 15 | 2.2 | 0.75 | 2.2 | 14 | 3.6 | 3 | 300 | 400 | 250 | 100 |
| WPG-400 | ~400 | ~42 | 15 | 2.2 | 0.75 | 2.2 | 14 | 3.8 | 3 | 400 | 500 | 250 | 100 |
Core Technologies:
WPG Combined DAF System:
Enhanced Contaminant Capture: Combines dissolved air flotation with
advanced flocculation and solid-liquid separation modules,
generating ultra-fine bubbles (20-50μm) to remove oils, TSS, and
colloidal particles.
Optimized Efficiency: Achieves 40-60% higher contaminant removal
vs. conventional DAF systems, with reduced chemical dosage and
energy consumption.
Applications: Industrial wastewater (food processing,
petrochemicals), municipal sewage pretreatment, and stormwater
treatment.
Microsand-Loaded Multi-Effect Clarification:
Microsand Acceleration: Uses micron-grade quartz sand as a carrier
to enhance flocculation, boosting sedimentation rates and
stability.
Ultra-Rapid Treatment: Operates at a surface load of 40-65 m³/m²·h
with total retention time <20 minutes, ideal for high-flow
facilities.
Performance Metrics:
SS/TP Removal >90%, COD Reduction up to 40%
Effluent Quality: TP <0.1 mg/L, turbidity <5 NTU
Applications: Overflow pollution control, municipal WWTP tailwater
polishing, and drinking water pretreatment.
Project Case
Certificate
| API-5LD AUTHENTICATION | American Petroleum Institute API 5LC Certificate | ASME Certificate in the United States | EU PED&AD2000 certificate | ABS classification society certification certificate in the United
States | DNV Det Norske Veritas Certificate | RINA Italian Bureau of Shipping Certificate | BV French Bureau of Shipping certification | LR Lloyd's Register Certificate of Approval | Customs Union EAC Certificate | Russian GOST certificate |
 |  |  |  |  |  |  |  |  |  |  |
