5m3/H Water Treatment Equipment Micro Sand Loading Flocculation Clarification Equipment

Ask Lasest Price
Brand Name :	EVEREST
Model Number :	WPG-5
Certification :	lS09001,IS014001, ISO45001, (TS ) Grade A, PED2014/68/EU,AP1 5LC, API 5LD, ASME, CCS, LR, DNV , BVRINA and ABS.
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T
Supply Ability :	800 units/year
Delivery Time :	15-21working days

Add to Cart

Product Details
Company Profile

5m3/H Water Treatment Equipment Micro Sand Loading Flocculation Clarification Equipment

Optimized Water Treatment with Micro Sand Loading and Enhanced Flocculation in Multi Effect Clarification Equipment

Product Overview

The WPG Combined Dissolved Air Flotation System is a next-generation water treatment solution that integrates dissolved air flotation (DAF) with enhanced flocculation and high-efficiency sedimentation. By introducing micron-level quartz sand as a carrier, the system significantly strengthens the flocculation process, accelerates sedimentation, and improves contaminant removal efficiency.

This highly integrated system is designed for overflow pollution control, municipal sewage plant tailwater improvement, and water plant pre-treatment. With a compact footprint and low operating costs, it ensures consistent and stable effluent quality while meeting stringent discharge standards.

How It Works

Dosing and Coagulation
- Coagulants and flocculants are added to the raw water to form flocs.
Micro-Sand Enhanced Flocculation
- Micron-level quartz sand strengthens the floc structure and increases the sedimentation rate.
Efficient Sedimentation
- The sedimentation section achieves a high surface load of 40–65 m³/m²·h with a total residence time of less than 20 minutes.
Mud-Sand Separation and Recycling
- The system efficiently separates sludge from micro sand and recycles the sand for continuous use.
Dissolved Air Flotation (DAF)
- Microbubbles (5–10 μm) attach to flocs, increasing buoyancy and accelerating the separation of suspended particles and contaminants.

 Modelspecifications andrelated technical parameters

Model	Capacity m³/h	Dissohedair quantity	Power Kw				Dimension(m)			Nozzle list
Model	Capacity m³/h	Dissohedair quantity	Reflowpump	Exhaust	Scavenger	Mixer	length	width	height	Iniet(A)	Outlet(B)	Sludge outlet(C)	Empty mouth(D)
WPG-1	~1	~0.7	0.55	0.55	0.2	0.4	1.7	0.55	1.1	32	32	40	32
WPG-2	~2	~1	0.55	0.55	0.2	0.4	2.8	0.65	4.5	40	40	50	40
WPG-3	~3	~2	0.75	0.55	0.2	0.4	3.5	0.8	1.6	80	80	80	50
WPG-5	~5	~3	1.1	0.55	0.2	0.75	4	1	1.7	80	80	80	50
WPG-10	~10	~4	1.5	0.75	0.2	0.75	5	1.2	2	100	100	100	80
WPG-15	~15	~5	2.2	0.75	0.2	0.75	5.5	1.5	2	125	125	100	80
WPG-20	~20	~7	3	0.75	0.2	0.75	5.8	1.8	2	150	150	100	80
WPG-30	~30	~8	3	0.75	0.2	0.75	6	2	2.1	150	150	100	80
WPG-40	~40	~9	4	0.75	0.2	0.75	7	2.2	2.1	200	200	100	80
WPG-50	~50	~10	5.5	0.75	0.2	0.75	7.2	2.5	3	200	200	100	80
WPG-60	~60	~10	5.5	0.75	0.2	0.75	7.4	2.5	3	200	200	100	80
WPG-70	~70	~12	5.5	0.75	0.2	1.1	7.6	2.5	3	200	200	100	80
WPG-80	~80	~12	5.5	0.75	0.2	1.1	7.8	2.5	3	200	200	100	80
WPG-100	~100	~15	5.5	0.75	0.2	1.1	8	2.5	3	200	250	100	100
WPG-120	~120	~15	5.5	0.75	0.4	2.2	8.5	2.5	3	250	250	200	100
WPG-150	~150	~30	7.5	1.5	0.4	2.2	9	3.1	3	250	250	200	100
WPG-200	~200	~30	7.5	1.5	0.4	2.2	10	3.1	3	250	350	250	100
WPG-300	~300	~42	15	2.2	0.75	2.2	14	3.6	3	300	400	250	100
WPG-400	~400	~42	15	2.2	0.75	2.2	14	3.8	3	400	500	250	100

 Application field

Treatment of theindustrial wastewaterin

chemical,food,woolspinning,slaugh-tering,

brewing,oredressing and washingindustries

Domestic sewage pretreatment and sludge thickening

Papermaking white water pulp recyclingand water reuse

Advanced treatment of fluorine-containing wastewater such as coal mines, photovoltaics, batteries, etc

Removal of various heavy metal ions in electroplating wastewater

Removal of impurities from tanning wastewater

Separation of oil refining wastewater and oil pollution

Certificate

API-5LD AUTHENTICATION	American Petroleum Institute API 5LC Certificate	ASME Certificate in the United States	EU PED&AD2000 certificate	ABS classification society certification certificate in the United States	DNV Det Norske Veritas Certificate	RINA Italian Bureau of Shipping Certificate	BV French Bureau of Shipping certification	LR Lloyd's Register Certificate of Approval	Customs Union EAC Certificate	Russian GOST certificate

Upgrade your wastewater treatment process with our advanced WPG Combined Dissolved Air Flotation System — delivering superior performance, lower costs, and consistent effluent quality.
